photo of Marquis C946

Marquis C946

Highest performance Quad Intel Xeon personal supercomputer

  • Intel C602J chipset providing excellent performance and stability
  • Four Intel Xeon E7-4800v3 or E7-8800v3 series processors
    • Up to 18 cores and 45MB L3 cache
    • Up to 9.6GT/s QuickPath Interconnect
  • Up to 2TB DDR4 ECC registered memory
    • Dual Channel memory busses
    • Thirty two DIMM slots for optimal expansion
  • Onboard cost-effective 10Gigabit Ethernet option
  • Nvidia PCI-Express graphic with multi-head display
  • Pedestal Chassis with 1400W hotswap power supply
    • High efficiency Platinum Level power supply
    • SAS back plane with five hotswap HD bays
    • 24X DVD+-RW dual layer optical recorder
    • Optional 4U rack conversion kit
  • Real time monitoring of system health status
  • Serial Console Redirection for remote management
  • Onboard Remote Server Management over LAN using IPMI 2.0
  • 32-bit or 64-bit Linux operating system

Three year limited warranty

full specs tech notes

Compare all ASL workstation models

Marquis C946-T Marquis C946-SR
Processor 4 x Xeon® Model E7-4830v3 (12-core) 4 x Xeon® Model E7-4830v3 (12-core)
Memory 32GB DDR4-2133 ECC registered 32GB DDR4-2133 ECC registered
Storage Controller Onboard C602J SATA 6Gbs 3ware 9750 SAS2/SATA 6Gbs RAID controller
Network Controller Onboard Intel i350 dual-port Gigabit Onboard Intel i350 dual-port Gigabit
Starting Price
$13,994
$14,601
Marquis C946-SST Marquis C946-SRT
Processor 4 x Xeon® Model E7-4830v3 (12-core) 4 x Xeon® Model E7-4830v3 (12-core)
Memory 32GB DDR4-2133 ECC registered 32GB DDR4-2133 ECC registered
Storage Controller LSI 3008 SAS3/SATA 12Gbps controller 3ware 9750 SAS2/SATA 6Gbs RAID controller
Network Controller Onboard Intel X540 dual-port 10Gigabit Onboard Intel X540 dual-port 10Gigabit
Starting Price
$14,228
$14,835
